Technical Specifications
| Flow Range | 0.03 ft/s to 16 ft/s (0.01 m/s to 5.0 m/s) |
| Accuracy | ±1.0% |
| Pipe Size | Clamp-on 1 in to 48 in (25 mm to 1200 mm) |
| Fluid | Water |
| Outputs | OCT Pulse output 0 Hz to 500 Hz Analog output 4 mA to 20 mA, max load 750 Ω |
| Communication Interface | RS485 MODBUS |
| Power Supply | 10 VDC to 36 VDC or 1 A |
| Keypad | 16 (4 × 4) key with tactile action |
| Display | 20 × 2 lattice alphanumeric back lit LCD |
| Temperature | Transmitter 14 °F to 122 °F (–10 ℃ to 50 ℃) Transducer 32 °F to 176 °F (0 ℃ to 80 ℃) |
| Humidity | Up to 99% RH, non-condensing |
