Overview
Enviro Testers Ozone Tester is mainly used for ozone concentration measurement in the pipeline of ozone generator, which can continuously detect ozone concentration in the outlet generator. It is used to detect the ozone gas in a variety of industrial environment and can also be used to detect the ozone gas in the environment of pipeline, container and so on. It is widely used in the industry of pharmaceutical, chemical, municipal, sewage treatment, etc., to measure the outlet concentration of the ozone generator and the output of the ozone generator.
Features
- UV absorption method with high accuracy
- Outdoor installation, waterproof
- High clear digital backlight display
Technical Specification
| Measurement method: | UV light double optical receiver with high precision measurement |
| Light source system | German long-life ultraviolet lamp (253.7 nm wavelength) |
| Detection range | 0 g/m3NTP to 200 g/m3NTP (Optional range: 0 g/m3 to 100 g/m3,0 g/m3 to 200 g/m3,0 g/m3 to 250 g/m3 |
| Display resolution | 0.01 g/m3 |
| Input gas flow | 1.0 L/min to ±0.2 L/min |
| Input pressure | <14.50 PSI (<0.1 MPa) |
| Zero shift | <±0.3% F.S (MAX: ±0.6 g/m3) |
| Working voltage | 110 V to 220 V |
| Responsive time | <2 S |
| Sampling port diameter | 0.23 in x 0.15 in (6 mm x 4 mm) |
| The accuracy of detection | ±3% readings |
| Communication mode | RS 485 |
| Output mode | 4 mA to 20 mA, linearity |
| Power | AC 220 V |
| Hole size: | 145 x 68 |
| Remarks | 1 mg/L = 1 g/m3 = 467 PPM |
| Size: | 6.10 in x 3.07 in x 9.44 in (155 mm x 78 mm x 240 mm) |
| Weight | 4.40 lbs (2 kg) |
