Technical Specifications
| Gas Detection | Single Gas, TWA, STEL |
| Gas Sensor | Electro to chemical sensor catalytic combustion Sensor, PID sensor |
| Gas Range | As per request |
| Alert Value | As per request |
| Accuracy | +3 % F. S |
| Response Time | T 90 < 30 s |
| Humidity | <95% RH no condensation |
| Display | Large STN LCD indicates real time and system state |
| Alarm | Audible and visual, vibration =85 dB the higher of buzz frequency, the higher gas concentration is. Can be customized with no alarm |
| Charging Time | 4 h to 6 h |
| Sampling Method | Natural diffusion |
| Power Supply | 3.7 V DC 1200 mAh rechargeable Li-ion battery |
| Fault Indication | Indications of Zero-point drift and sensor failure |
| Duration of Operation | <300 h (non-stopped) |
| Ingress Protection | IP65 |
| Dimension | 4.01 in x 2.2 in x 1.02 in (102 mm x 56 mm x 26 mm) |
| Operating Temperature | -22 F to 122 F ( -30 ℃ to 50 ℃) |
| Net Weight | 264 lb (0.12 kg) including battery |
