Overview
Enviro Testers Portable Digital Coating Thickness Gauge adopts two thickness-measuring methods: magnetic induction (ferrous) and eddy current (non-ferrous). It can rapidly, non-destructively, and precisely measure the thickness of non-magnetic coating on magnetic metal substrate, and the thickness of non-conductive coating on non-magnetic metal substrate. This paint meter can be equipped with 6 optional probes for different applications. It is suitable for both field testing and laboratory research.
Features
- Two calibration methods for better correction
- Integrated with printer to print the statists values
- Low battery indication and error alarm
- Backlight for the screen
- Auto or manual shutdown
Technical Specifications
| Measuring Methods | Magnetic Induction |
| Measuring Range | 0 μm to 1250 μm |
| Minimum Resolution | 0.1 μm |
| Tolerance (Zero Point Calibration) | ±(3%H+1) μm |
| Tolerance (Two Points Calibration) | ± [(1 to 3) %H+1] μm |
| Min. Curvature Radius | Convexity 0.05 in (1.5 mm) |
| Min. Testing Area Diameter | 0.27 in (7 mm) |
| Critical Thickness of Substrate | 0.019 in (0.5 mm) |
| Calibration | Zero and Foil Calibration |
| Interface | USB2.0 |
| Statistic | Number of Measurement, Mean, Standard Deviation, Maximum and Minimum |
| Data Memory | 500 Readings |
| Limits | Adjustable with Alarm |
| Power | Li Rechargeable Battery |
| Operating Environment | Temperature: (32 °F to 104 °F) 0 ℃ to 40 ℃ |
| Dimensions | 215 in × 84 in × 42 in (215 mm × 84 mm × 42 mm) |
