Features
- Built-in white plate parameters. No need to calibrate each time
- Double locating: illuminating locating and precise cross locating
- Switchable double measurement end face
- New integrating sphere optical path design
- Equipped with rechargeable-capacity Li-ion battery
- Hand-head structure, small and convenient
Technical Specifications
| Illuminating or Viewing Geometry | 8/d |
| Measuring Aperture | Φ 0.31 in (8 mm),
Φ 0.15 in (4 mm) |
| Detector | Silicon photoelectric diode |
| Color Space | CIEL x a x b x C x h x CIEL x a x b |
| Color Difference Formula | E x ab Lx a x b E x C x h |
| Light Source | D65 |
| Light Source Device | LED blue light excitation |
| Errors Between Each Equipment | ≤ 0.80 E x ab,
≤ 0.50 E x ab |
| Storage | 100 pcs standards, 5000 pcs samples |
| Repeatability | Standard deviation within ΔE x ab 0.08
Average of 30 measurements of standard white plate |
| Lamp Life | 3 years, more than 1 million time;
5 years, more than 1.6 million time; |
| Charging Time | 8 h, 100 % electricity;
2 h (8 h for first charge), 100 % electricity; |
| Measurement Times Before Recharging | 3000 times in 8 h |
| Data Interface | USB |
| Optional Accessory | Miniature thermal printer |
| Power Supply | Rechargeable lithium-ion battery 3.7 V 3200 mAh |
| Operating Temperature/Humidity Range | 14 °F to 104 °F (-10 ℃ to 40 ℃), relative humidity 0 % to 85 % with no condensation |
| External Size | 8 in x 2.6 in x 3.1 in (20.5 cm x 6.7 cm x 8 cm),
8 in x 2.76 in x 3.94 in (20.5 cm x 7 cm x 10 cm) |
| Net Weight | 17.64 oz (500 g),
15.87 oz (450 g) |
