Features
- Built-in white plate parameters. No need to calibrate each time
- Double locating illuminating locating and precise cross locating
- Switchable double measurement end face large area stable
- New integrating sphere optical path design
- Equipped with rechargeable-capacity Li-ion battery
- Configured CQCS3 software to realize more functions
- Hand-head structure, small and convenient
Technical Specifications
| Detector | Silicon photoelectric diode |
| Colour Space | CIEL x a x b x C x h x CIEL x a x b x |
| Colour Difference Formula | E x ab L x a x b E x C x h |
| Power Supply | Rechargeable lithium-ion battery 3.7 V at 3200 mAh |
| Light Source Device | LED blue light excitation |
| Illuminating/Viewing Geometry | 8 or d |
| Measuring Aperture | Φ0.16 in (Φ4 mm), Φ0.31 in (Φ8 mm) |
| Errors Between Each Equipment | ≤0.80E x ab, ≤0.40E x ab |
| Storage | 100 pcs standards, 5000 pcs samples 100 pcs standards, 20000 pcs samples |
| Repeatability | Standard deviation within ΔE x ab 0.08 Average of 30 measurements of standard white plate |
| Lamp Life | 3 years, more than 1 million time |
| Charging Time | 8 hours to 100% electricity |
| Measurement Times Before Recharging | 3000 times in 8 hours |
| Operating Temperature or Humidity Range | 14 °F to 104 °F (-10 ℃ to 40 ℃) |
| Humidity | 0% to 85% with no condensation |
| External Size | 8.07 in x 2.63 in x 3.14 in (205 mm × 67 mm × 80 mm) |
| Net Weight | 17.63 oz (500 g) |
