Features
- 128 x 64 LCD monitor, easy installation
- Imported infrared sensors for high sensitivity
- Long-lasting lithium battery with auto-voltage protection
- Data backup and recovery
- Full English operation menu
Technical Specifications
| Measuring range | 0 ppm to 1000 ppm/100% |
| resolution | 0.1 ppm /1ppm /0.01% /0.1% |
| Accuracy | ≤±2% F.S |
| Repeatability | ≤±1% F.S |
| Zero drift | ±1% F.S/7 d |
| Span drift | ±1% F.S/7 d |
| Response time | T 90≤30 s |
| Warm-up time | ≤45 min |
| Sample gas flow rate | 1000 mL/min ±100 mL/min |
| Sample gas pressure | 14.50 PSI (100 kpa)≤entrance pressure ≤29.01 PSI (200 kpa) |
| Power Supply | 100 V to 240 V AC 50 Hz to 60 Hz 1A |
| Ambient temperature | 23 °F to 113 °F (-5 ℃ to +45 ℃) |
| Environment humidity | ≤90% RH |
| Dimensions | 10.24 in x 5.71 in x 12.99 in (260 mm x 145 mm x 330 mm) |
| Weight | 7.72 lb (3.5 kg) |
