Overview
Enviro Testers Portable Medical Spectrophotometer Gloss Meter is developed with independent intellectual property rights. It features with stable performance, precise measurement and powerful functions in the leading position of the same industry. In the R&D process, our scientists and engineers measured various colour samples from dark to light, white to black, and other standard colour boards provided by ISO (International Standardization Organization). The parameters of test results are integrating with international standards. We also analysed the parameters from Japan, American and Germany spectrophotometers. The differences of Lab absolute value between them are within ±1.5. Compared the Lab value between NS810 and Japan spectrophotometer, when measuring any color objects, the biggest Lab difference is within ±1.0. This is a breakthrough of high technology which realizes to be fully compatible with international market.
Technical Specifications
| Illumination/Observation System | D/8 (diffused illumination, 8-degree viewing angle) Conforms to CIE No.15, GB/T 3978. |
| Integrating Sphere Size | 2.28 in (Φ58 mm) |
| Wavelength Range | 400 nm to 700 nm |
| Wavelength Pitch | 10 nm |
| Reflectance Range | 0 % to 200 % |
| Measuring Aperture | 0.32 in (Φ8 mm) |
| Color Difference Formula | ΔE x ab, ΔE x uv, ΔE x 94, ΔE x cmc (2:1), ΔE x cmc (1:1), ΔE x cmc (l:c), CIE 2000ΔE x 00, ΔE (h) |
| Observer | 2 °or 10 ° |
| Measurement Time | 1.5 s |
| Repeatability | Spectral Reflectance: standard deviation within 0.1 % (400 nm to 700 nm: within 0.2 %) Colorimetric Value: Standard deviation within Delta E x ab 0.04 (Measurement conditions: white calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.) |
| Inter Instrument Agreement | Within Delta E x ab 0.2 (Average for 12 BCRA Series II color tiles) |
| Battery | Li-ion battery. 2800 times within 8 hours. |
| Lamp Life | 5 years, more than 1.6 million measurements |
| Display Screen | TFT 3.5-in, Capacitive Touch Screen |
| Interface | USB or RS-232 |
| Data Memory | 1000 Standards, 15000 Samples |
| Weight | 1.32 lb (600 g) |
| Dimensions | 3.54 in × 3.03 in × 9.06 in (90 mm x 77 mm x 230 mm) |
| Operating Temperature | 32 °F to 104 °F (0 ºC to 40 ºC) |
| Storage Temperature | -4 °F to 122 °F (-20 ºC to 50 ºC) |
