| Gas Type |
Multi gas type (Could be customized) Multiple gas analyzer |
| Measurement Range |
0 ppm to 1 ppm, 10 ppm, 100 ppm, 1000 ppm, 5000 ppm, 10000 ppm; 0% LEL to 100% LEL, Temperature and humidity range: 104 °F to 248 °F (-40 ℃ to 120 ℃) / 0% RH to 100% RH |
| Sensor Type |
Catalytic combustion sensor; Electrochemical sensor; PID sensor; Infrared sensor; 1 to 6 sensors, support the temp/humidity sensor and other type sensor. |
| Accuracy |
≤±3% Multiple gas analyzer, gas detector, portable gas detector |
| Response Time |
≤20 s (T90) portable gas analyzer, gas analyzer |
| Linearity |
≤±1% Multiple gas analyzer |
| Resume Time |
≤20 s Multiple gas analyzer, gas detector. |
| Repeatability |
≤±1% |
| Zero Drift |
≤±1% (F.S/year) |
| Sampling |
Pump-suction Speed of 2 L/min |
| Alarm Mode |
Audible-visual alarm |
| Working Mode |
Real-time measurement and timing measurement(For timing measurement mode, the displayed data is average concentration in the timed period.) |
| Storage Mode |
Real-time storage and timed storage;Automatically saving and manually saving are available, up to 100,000 groups data, user can view history data on the display. |
| Print Mode |
Optional mini printer. User can set the print interval, auto-printing mode or manual printing mode |
| Pump Mode |
Standard mode or vacuum mode. It can work in micro negative pressure environment. |
| Data Resume |
Factory default setting with one-key operating |
| Self-checking |
System checking for battery energy, display status, sensor and hardware |
| Protection Grade |
IP 65 |
| Working Temp |
-22 °F to 140 °F (-30 ℃ to 60 ℃) |
| Ex Grade |
Exdll CT4 (IA) |
| Working Humidity |
≤95% RH (non-condensing) |
| Power Supply |
6000 mA rechargeable lithium battery |
| Optional |
Wireless transmitters, transmission distance is 39370 in to 118110 in (1000 m to 3000 m), more optional GPRS transmission over a long distance |
| Accessories: |
Case, User manual, Certification,12 V DC Charger, USB cable, Sample handle, 31.49 in (0.8 m) hose |
| Working Pressure |
-4.35 PSI to 14.5 PSI (-30 Kpa to 100 Kpa) |
| Weight |
6.61 lb (3 kg) |
| Dimension |
9.0551 in × 4.7244 in × 8.6614 in (230 mm × 120 mm × 220 mm) |
