Overview
Enviro Testers portable precision handheld colorimeter according to the market demand for chromatic meter research and development, no matter from the precision, the core technology, have price ratio can be perfect. This product can precision chromatic meter with tens of thousands of test components can measure all need chromatic meter to measure the market objects, whether solid, liquid, granule or paste can perfect control. The chromatic aberration meter is accurate and stable, easy to operate, easy to understand and economical.
Features
- It is economical and easy to operate
- Color box packaging, convenient transportation.
- Double positioning function of light and cross
- Rechargeable lithium-ion batteries are available
- Higher short-term repeatability accuracy AE 0.03
- With built-in white board parameters
- No need to connect computer to start up and use – easy to measure
- Phi 0.16 in (4 mm) diameter, suitable for more measuring occasions
Technical Specifications
| Measurement Geometry | 8° per d |
| Measuring Aperture | Φ 0.16 in (4 mm) |
| Light Source | D 65 (LED blue light excitation) |
| Interface | USB |
| Lamp Life | 5 years, more than 1.6
million measurements |
| Charging Time | 8 hours, 100% electricity |
| Color Spaces | CIE-La x b x C x H
CIE-L x a x b CIE-XYZ |
| Positioning Way | Light orientation and cross orientation |
| Detector | Silicon photoelectric diode |
| Measurement End Face | Large stable end-face and small concave-convex end-face |
| Storage | 100 pcs standards
10000 pcs samples |
| Locating | Illuminating Locating or Cross Locating |
| Inter-Instrument Error | ≤ 0.20 Δ E x ab |
| Color Difference Formula | △ E x ab |
| Dimension | 8.07 in x 2.64 in x 3.15 in (205 mm x 67 mm x 80 mm) |
| Weight | 17.63 oz (500 g) |
