Technical Specifications
| Principle | The displacement differential inductance |
| Stylus | Natural Diamond, 900B cone angle, Sum tip radius |
| Force | < 4mN Ruby |
| Skid | Longitudinal radius 40 mm |
| Accuracy | No more than ‡ 10% |
| Repeatability | No more than 6% |
| Power Supply | Built-in 3.7V Lithium-ion battery, Charger: DC 5V, 800mA / 3hour |
| Working Time | More than 20 hours |
| Outline Dimension LXWXH | (141 mm x 55 mm x 40 mm) 5.5512 in × 2.1654 in × 1.5748 in |
| Weight | About (400 g) 0.88 lb |
