Features:
- Built-in Chargeable Lithium Battery Can Continuously Work 50 Hours
- 4 Lines Display Velocity, Flow Rate, Volume and Meter Status
- Clamp-on Mounted, Unnecessary Pipe Cutting Or Processing Interruption
- Built-in Data Storage Is Optional
- Selecting Temperature Sensor PT1000 To Achieve Thermal Energy Measurement Function
- Suitable For DN 20 to DN 6000 Flow Measurement By Selecting Different Size Transducers
- Bi-directional Measurement, Flow Range From 0.01m/s To 12 m
Technical Spesifications:
| Measuring Principle | Transit-time |
| Velocity | 0.01 m/s to 12 m/s, Bi-directional Measurement |
| Resolution | 0.25 mm/s |
| Repeatability | 0.1% |
| Accuracy | ±1.0% R |
| Response Time | 0.5 s |
| Sensitivity | 0.003 m/s |
| Damping | 0 s to 99 s(settable by user) |
| Suitable Fluid | Clean or tiny amounts of solids, air bubbles liquid, Turbidity <10000 ppm |
| Power Supply | AC: 85 V to 265 V DC:12 V to 36 V / 500 mA |
| Installation | Portable |
| Protection Class | IP66 |
| Operating Temperature | -40 ℃ to +75 ℃ (-40 °F to 167 °F.) |
| Enclosure Material | ABS |
| Display | 4 x 8 Chinese Or 4 x 16 English,Backlit |
| Measuring Unit | meter, ft, m³, liter, ft³ ,gallon,barrel etc. |
| Communication Output | 4 mA to 20 mA, OCT, RS485 (Modbus-RUT), Data Logger |
| Energy Unit | Unit :GJ,Opt: KWh |
| Security | Keypad Lockout, System Lockout |
| Size | 10.63 in x 9.69 in x 6.89 in (270 mm x 246 mm x 175 mm) |
| Weight | 6.61 lb (3 kg) |
