Overview
Enviro Testers Portable Ultrasonic Thickness Gauge Meter is used for thickness measurement of various pipelines and pressure vessels and can also be used for accurate measurement of various plates and various processed parts. It can measure the thickness of any hard material such as aluminum, copper, brass, zinc, polyethylene, polyvinyl chloride, gray cast iron, and also can measure the thickness of other good ultrasonic conductor materials such as steel, cast steel, glass, ceramics, and plastics.
Features
- Provide Bluetooth data output choice
- Coupling symbol indication
- Automatic memory material code
- Use USB/RS-232 data output
- Bidirectional measurement Thickness and velocity interchangeably quantifiable
- Utilizing cutting-edge, energy-efficient microprocessor technology
Technical Specifications
| Housing Material | Aluminum Alloy |
| Display | Large Screen LCD |
| Measuring Range | 0.02 in to 15.7 in (0.75 mm to 400 mm) |
| Resolution | 0.001 in or 0.1 mm |
| Accuracy | (0.5 % n + 0.05) |
| Sound Velocity | 500 m/s to 9.990 m/s |
| Lower Limit of Pipes | 0.5 in x 0.07 in x 0.7 in x 0.11 in (15 mm x 2 mm x 20 mm x 3 mm) |
| Temperature | 32 °F to 104 °F (0 ºC to 40 ºC) |
| Power Supply | 2 V x 1.5 V AA (UM 3) Battery |
| Dimensions | 5.1 in x 2.9 in x 1.2 in (130 mm x 76 mm x 32 mm) |
| Weight | 0.74 lb (340 g) (Not Including Batteries) |
