Technical Specifications
| Measure Parameters | Refractive index(nD), Brix (%), Temperature (° C) |
| Measure Range | 0% to 53% |
| Min Resolution Ratio | Brix: 0.1% (Range for 15% & 53%) |
| Measurement Accuracy | Brix: ±0.1% (standard) |
| Operating Current | ≤200 mA |
| Display Menu | Refractive index(nD), Brix (%), Temperature (° C) |
| Output | 4 mA to 20 mA, 4 mA to 20 mA + RS485 optional |
| Power | 12 V DC to 24 V DC |
| Wetted Parts Material | Prism: sapphire, Prism stage: SS316L |
| Max Pressure | 1 MPa |
| Protection Grade | IP65 |
| Process Connection | 1/2NPT, other size supply free adaptor |
| Record Output Cable | 2 M,3 M,5 M,10 M optional |
| Temperature Sensor | Thin film platinum sensor |
| Measurement Temperature | 32 °F to 185 °F (0 ° C to 85° C) |
| Environment Temperature | 50 °F to 140 °F (10 °C to 60 °C) |
| Instrument Size | 9.05 in × 6.69 in × 2.55 in (230 mm × 170 mm × 65 mm) |
| Weight | 4.40 lb (2 kg) |
