Features
- This unit was designed according to the IEC651 TYPE2& ANS S1.4 TYPE2 for sound level meters
- Measurement range 30 dB to 130 dB
- With two equivalent weighted sound pressure levels, A and C
- Fast & Slow dynamic characteristic modes
- AC and DC signed output for frequency analyzer level recorder, graphic recorder
Technical Specifications
| Accuracy | 1.5 dB |
| Frequency Range | 31.5 Hz to 8.5 KHz |
| Linearity Range | 50 dB |
| Measuring Level | 30 dBA to 130 dBA |
| Resolution | 0.1 dB |
| Sampling Rate | 2 s |
| Power Supply | 1 x 9 V |
| Temperature | 32 ºF to 104 ºF (0 ºC to 40 ºC) |
| Dimensions | 7.8 in x 2.4 in x 1.1 in (200 mm x 63 mm x 30 mm) |
