Overview
GAOTEK Radiation Survey Meter using high sensitive NaI as detector, fast response, wide range, used to monitor high and low energy X-ray, gamma ray in a variety of radioactive workplace. The instrument uses color LCD as a display, with backlight brightness adjustable function. The instrument has a threshold alarm function, the alarm threshold can be arbitrarily set in the measurement range, there is timing measurement and recording function, and can realize the alarm record query function.
Technical Specifications
| Measuring Range | Dose rate: 0.01 µSv/h to 200.00 µSv/h, Cumulative dose: 0.00 µSv to 9.99 Sv |
| Sensitivity | ≥350 CPS/μSv/h |
| Energy Range | 15 Kev to 3 Mev |
| Relative error | ≤± 8% (at 200.00 µSv/h) |
| Measuring Time | 5 s to 120 s |
| Alarm threshold | The cumulative dose and dose rate thresholds can be set arbitrarily. |
| Measurement method | Real-time measurement and timing measurement |
| Power Supply | Two AA Battery |
| Unit | µSv/h, µGy/h, µSv, CPS |
| Dimensions | 16.54 in x 7.09 in x 3.46 in (420 mm x 180 mm x 88 mm) |
| Weight | 2.98 lb (1.35 kg) |
