Overview
Enviro Testers range coating thickness is a large range (measuring range: 0 to 6000 um) test magnetic metal matrix (such as iron Fe, cobalt Go, nickel Ni) on the thickness of the non-magnetic coating (such as aluminum, chromium, copper, zinc, tin, enamel, rubber, plastic, paint, etc.) Single key can complete zero calibration, calibration, measurement and other operations, a large range single thickness gauge is a small coating measuring instrument.
Features
- Large measuring range 6000 μm
- LR100A can measure thickness of non magnetic
- Durable integrated ruby probe and easy to carry
- More wearable and precise
- Power down after 60 seconds of no activity
- Ergonomically designed: non slip host
- One key and one hand operating
Technical Specifications
| Customized Support | OEM ODM OBM |
| Measuring Range | 0 to 6000 μm |
| Resolution | 1 μm |
| Working Principle | Magnetic |
| Accuracy | ± [(1% to 3%) H + 1 μm] |
| Minimum Measuring Area | Φ 0.5 in (Φ15 mm) |
| Minimum Curvature | Convex radius: 0.1 in Convex radius: (5 mm) Concave radius: 0.9 in Concave radius: (25 mm) |
| Power | AAA battery 4 pieces |
| Working Temperature | 14°F to 140°F(- 10°C to 60°C) |
| Size | 4.4 in x 2.7 in x 1.1 in (112 mm x 69 mm x 28 mm) |
| Weight | 0.1 lb (82 g) |
