Technical Specifications
| Rotor | R2 – R7 (6, marking)R1 (Optional) |
| Sample Dosage | 500 ml |
| Measurement Error (Newtonian Liquid) | ±1% |
| Repetition Error (Newtonian Liquid) | ±0.5% |
| Display Shear Response Or Shear Rate | Standard configuration |
| Timing Function | Standard configuration |
| Display Viscosity Curve | Shear rate – viscosityTemperature – viscosityTime – viscosity |
| Kinematic Viscosity | Density of sample to be input |
| Temperature Measurement | Standard temperature probe interface (need to select temperature probe) |
| Auto Scan | Automatically scan and recommend the best combination of rotor and speed |
| Maximum Measurement Range | Automatic display of the selected combination of rotors and rotational speeds in a measurable range of viscosity |
| Self-built Measurement Program | Save up to 30 groups (including rotor, speed, temperature, time, etc.) |
| Source | Wide voltage work (110 V or 60 Hz or 220 V or 50 Hz) |
| Outline Dimension | 11.81 in x 11.81 in x 17.72 in (300 mm × 300 mm × 450 mm) |
