Overview
Enviro Testers Rotational Viscometer is a precision instrument which is suitable for measuring absolute viscosity and apparent viscosity of various Newtonian liquids in laboratory and factory. The viscometer can be used to measure the viscosity of petroleum, resin, paint, ink, slurry, cosmetics, cream, medicine, asphalt, etc. For different viscosity liquid or different measurement requirements, different measurement units can be selected for measurement. The viscometer has the advantages of small volume, light weight, convenient use, simple maintenance, durability and rapid and reliable determination of liquid viscosity.
Features
- Instrument driven by micro synchronous motor, constant speed unaffected by load or power supply voltage
- Two test units with measuring container and rotating cylinders with shafts for diverse sample testing
- Novel design with arc dial for easy readability
Technical Specifications
| Power Supply | AC 220 V ±10%, 50 Hz |
| Measurement Range | 145.038 pSi.s to 145.038 x 15374 pSi.s (1 mPa.s to 1×106 mPa.s) |
| Measuring Accuracy | ±5% (For Newtonian Liquids) |
| Measuring Unit | Unit II and Unit III |
| Rotating Speed | 750 RPM, 75 RPM, 7.5 RPM |
| Ambient Temperature | 41 °F to 95 °F (5 ˚C to 35 ˚C) |
| Relative Humidity | ≤80% |
| Overall Dimension | 6.69 in x 5.11 in x 17.32 in (170 mm × 140 mm × 440 mm) |
