Features
- The basic accuracy of the output of up to 0.02%, the output is displayed as 6 digits
- The output functions: DC voltage, DC current, ohms, analog transmitters
- Thermocouple, RTD, frequency, pulse, switch On-OFF
- The DC current output can provide 25 percent and 100 percent of manual stepping
- Automatic step and auto ramp output function
- The thermocouple output
- Provides high-precision automatic cold junction compensation
- ℃ or ℉ temperature display
- Outside with high-precision temperature probe, accuracy ±32.36 °F (0.2 ℃)
- Large-screen LCD displays multiple data can be displayed simultaneously DC current
- The operating performance is superior keyboard configuration
Technical Specifications
| Display and Backlight | Segment LCD dual display, White LED backlight |
| Power Supply | 4 x 1.5 V AAA alkaline batteries, Automatic shutdown: can set auto-off time from 0 to 60 minutes |
| Features | High Accuracy of 0.02% for source, 6 digits display for source. A dual, Liquid Crystal Display, White LED for backlight |
| Temperature Coefficient | 0.1 times the applicable accuracy, specification per degree F for 41 °F to 64.4 °F (5 °C to 18 °C) and 82.4 °F to 122 °F (28 °C to 50 °C) |
| Internal temperature compensation sensor range | from 32 °F to 104 °F (0 °C to 40 °C), Compensation error ≤±0.5℃ |
| Temperature probe accuracy | ±32.36 °F (0.2 ℃) |
| The range of the measured temperature is from | -4 °F to 212 °F (-20 °C to 100 °C) |
| Maximum voltage between any output terminal and earth | 30 Vp-p |
| Maximum output current | Approximately 25 mA |
| Accuracy | up to 0.02% |
| Battery | 9 V |
| Working Temperature and Humidity | 32 °F to 122 °F (0 °C to 50 °C), ≤80% RH non-condensing
104 °F to 122 °F (40 °C to 50 °C), ≤70% RH |
| Storage Temperature and Humidity | -13 °F to 140 °F (-25 °C to 60 °C), ≤90% RH non-condensing |
| Size | 8.07 in x 3.74 in x 1.65 in (205 mm x 95 mm x 42 mm) |
| Weight | 1.1 lb (500 g) |
