Features
- Using imported high-precision sensor
- 100,000 sets of data can be stored and storage interval available set minimum 5 s
- LCD display, can display the type of gas unit, gas concentration values, measured maximum, local time and ambient temperature
- English operation interface
- Gas concentration unit PPM, mg or m3 can quickly switch display
- Built-in micro sampling pump, the pump suction size ten stalls adjustable
Technical specification
| Precision | 2% FS |
| Display mode | LCD |
| Response time | ≤10 s |
| Linearity error | ≤±1% |
| Detection principle | Infrared |
| Sampling Method | Pump- suction, flow up 1 L/min, |
| Data logger | 100,000 sets of data can be stored |
| Resolution | 1 ppm, 0.01% VOL, 0.01% LEL |
| Storage interval | 2% FS |
| Response Time | Minimum 5 s |
| Repeatability | ≤±1% |
| Zero shift | ≤± 1% (F.S / Year) |
| Alarm mode | Sound, light, vibration |
| Recovery Time | ≤ 10 s |
| Humidity | 0% RH to 95% RH |
| Degree of protection | IP 66 |
| Operating time | 100 hours (off pump) |
| Temperature | -40 °F to 158 °F ( -40 ℃ to 70 ℃) |
| Dimension | 8.07 in × 2.95 in × 1.25 in (205 mm × 75 mm × 32 mm) |
| Weight | 10.58 oz (300g) |
