Features
- Drinking water or surface water or various water supply or industrial water treatment
- Signal output, RS485 Modbus or RTU protocol
- Convenient connection to third party equipment such as PLC, DCS, industrial control
- Immersion installation with 3 per 4 NPT pipe thread for easy submersible installation or installation in pipes and tanks
- IP68 protection grade
Technical Specifications
| Measuring Range | 0 μS per cm to 5000 μS per cm |
| Resolution | 1 |
| Precision | ± 1.5 % FS |
| Working Pressure | <0.6 MPa |
| Power Supply | 12 V DC to 24 V DC ± 10 % |
| Signal Output | RS485 Modbus or RTU |
| Wetted Material | ABS or SUS316L Default or PVC |
| Mounting Method | Immersion mounting, 3 per 4 NPT thread |
| Cable Length | 5 meters, other lengths can be customized |
| Temperature Compensation | Pt1000 |
| Calibration | Two point calibration |
| Protection Grade | IP68 |
| Power Consumption | <0.3Wat12 V |
| Working Temperature | 32 °F to 149 °F (0 °C to 65 °C) |
