Technical Specifications
| Control/Display | 5-inch color touch screen |
| Rotate Speed(r/min) | 0.3 CVT to 100 CVT A total of 998 RPM is available |
| Measuring Range | 0.6 million to 200 million mPa.s |
| Rotor | No. 1-4 (standard configuration)
Enhanced ultra-low viscosity adapter ULR(Optional) Small number of sample adapters (No.18,25,31,34 rotor) (Optional) |
| Specimen Sizes | No. 1-4 rotor: measuring range 10 M to 2 M
(300 to 400) ml ULR: measuring range 0.6 to 1000, 21 ml No. 18 rotor: measuring range 3 K to 10 K,7 ml No. 25 rotor:480 M to 1.60M; 9 ml No. 31 rotor:30 K to 100 K; 10.5 ml No. 34 rotor:20 K to 200 K; 11 ml |
| Measuring Error | ±1% (Newtonian liquid) |
| Repetitive Error | ±0.5% (Newtonian liquid) |
| Working Lower Supply | Wide voltage operation (110V / 60 hz or 220 V / 50 Hz) |
| Boundary Dimension | 11.81 in x 11.81 in x 17.71 in (300 mm × 300 mm × 450 mm) |
