Technical Specifications
| Flow Rate Range | 0 m/s to 10 m/s |
| Flow Rate Resolution | 0.001 m/s |
| Velocity Accuracy | 0.001m/s (when velocity <= 5m/s); 0.02m/s or 0.3% of actual peak velocity (whichever is greater) (when velocity > 5m/s) |
| Ultrasonic Level Range | 6.5m |
| Ultrasonic Level Accuracy | 0.001m |
| Ultrasonic Level Resolution | 0.0005m |
| Hydrostatic Level Range | 0 to 10m |
| Hydrostatic Level Accuracy | ±0.1% FS |
| Hydrostatic Level Resolution | 0.001 m |
| Temperature Range | -60 °F to 140 °F (-20 ℃ to 60 ℃) |
| Install | Special bracket |
| Material | Metal, POM, Rubber |
| Protection Class | IP68 |
| Powered By | DC12V/24V |
| Power Consumption | <90 mA during measurement; <25 mA during sleep |
| Communication Interface | RS485, Modbus |
