Technical Specifications
| Flow Range | 0.05 m/s to 5.0 m/s |
| Accuracy | ±1.0% F.S. |
| Repeatability | 0.8% F.S. |
| Measurement Tube Diameter | φ3 mm to φ12 mm |
| Storage Function | With daily, monthly and annual flow accumulation function |
| Output | OCT output, maximum load 600 Ω |
| Alarm Output | OCT upper and lower limit alarm function (option) |
| Communication Interface | RS485, support MODBUS communication protocol |
| Power Supply | 24 V DC |
| Cable Length | 6.56 ft. (2.0 m) |
| Keyboard | Four light touch keys |
| Display | OLED 128 x 64 dot matrix display |
| Units | /H, /ML, default m³/h |
| Accumulator | Six-digit flow accumulator |
| Housing Material | PP, PFA (optional) |
| Ambient Temperature | 0 °F to 122 °F (0 ℃ to 50 ℃) |
| Media Temperature | Normal temperature type: 0 °F to 122 °F (0 ℃ to 50 ℃) |
| Ambient Humidity | Relative humidity 0% to 90%, no condensation |
| Protection Class | IP54 |
