Features
- It can be used to measure the flow of open partially filled pipes (round pipes, rectangular pipes or other special-shaped pipes);
- Can be used for continuous measurement of municipal rainwater, waste water, sewage discharge and irrigation water pipelines;
- It can realize forward and reverse two-way flow measurement;
- The sensor can work reliably for a long time under harsh site and sewage water quality; Velocity measurement range 05-10m/s;
- The flow measurement accuracy is high, and it is not affected by factors such as downstream, direct flow, blockage, etc.;
Technical Specifications
| Nominal Diameter: | Circular pipe DN300 DN6000mm rectangular pipe: width ≤ 6m ≤ 6m |
| Measuring Accuracy | Water level ±2mm; velocity ±1.0%; flow ±1.5% |
| Measuring Range | Flow velocity 0.05 to 10m/s |
| Conductivity Of The Measured Medium | ≥20s/cm |
| Current Output Signal | 4 to 20mA/DC (Load resistance ≤ 500Ω) |
| Pulse Output Signal | 1 to 2000HZ |
| Digital Communication Interface | Rs232RS485 optional |
| Power Supply | 220V/AC or 12v/DC 24v/DC |
