Technical Specifications
| Display | 2 in (50.8 mm) black and white LCD with 128 x 64 resolution |
| Installation method | Threaded mounting/flange mounting |
| Ingress protection | IP65 |
| Measuring range | 0 m to 30 m |
| Accuracy | ± 0.5 % FS (optional ± 0.2 % FS) |
| Resolution | 0.039 in (1 mm) or 0.1%FS (maximum) |
| Temperature compensation | Automatic temperature compensation with temperature calibration function |
| Relative humidity | 10 % RH to 85 % RH |
| Current output | 4 mA to 20mA can set the measuring range of corresponding object position or distance, the maximum load is 500 Ω, and the output accuracy is 0.2 % FS |
| Communication | Isolated RS485 Modbus-RTU Communication Protocol |
| Relay output | Two independent normally open contacts with high/low setting and 250 V AC 3 A Max contact capacity |
| Power supply | 14 V DC to 28 V DC 85 V AC to 305 V AC，5 W Max，50 Hz/60Hz |
| Ambient temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Storage temperature | – 4 °F to 158 °F (- 20 °C to 70℃) |
