Overview
Enviro Testers ultrasonic thickness gauge has been designed to measure the material thickness calipers can’t measure, such as boilers, pressure vessels, armor of tanks, ship hulls, glass walls, tubes, etc. The ultrasonic thickness gauge can meet the standards of the European Union.
Features
- Measuring thickness of various good ultrasonic wave
- conductors as steel, aluminum, copper, glass etc
- Ultrasonic wave velocity or thickness display
- Manual material selection
- Ultrasonic wave velocity adjustable
- Ultrasonic wave velocity testing
- Coupling state display
- Shut down manually or automatically
- Low battery voltage indication
- Software calibrating to ensure high reliability.
- Digital display: 4 digitals.
- Ultrasonic wave frequency: 5 MHz
- Ultrasonic wave velocity: 1000 m/s to 9999 m/s
- Built-in calibration metal block 0.15 in (4.0 mm)
Technical specification
| Measurement Range | 0.047 in (1.2 mm) to 220 mm (8.66 in) |
| Resolution | 0.043 in (0.1 mm) |
| Measurement Rate | 0.6 s |
| Storage Temperature | -40 ℃ to +70 ℃ (-40 ℉ to +158 ℉) |
| Operating Temperature | 0 ℃ to 40 ℃ (32 ℉ to +104 ℉) |
| Digital Display | 4 digits |
| Operating Humidity | 10 % to 90 % RH |
| Velocity Range | 1000 m/s to 9999 m/s |
| Pipe Measures | 0.78 in x 0.11 in (20 mm x 3 mm) |
