Features
- Resolution from VGA to 25 MP
- Adopts GigE interface
- Support Windows and Linux
- Resolution from 1.3MP to 12MP
- Available in single board and C-mount
- Compatible with GigE or USB 3.0 Vision Protocol
Technical Specifications
| Resolution | 1280 px x 960 px |
| Pixel Size | 0.00014 in x 0.00014 in (3.75 um x 3.75 um) |
| Fps | 30 |
| Data Bit | 14 bits |
| Dynamic Range | 63 dB |
| Housing Size | 1.14 in x 1.14 in x 1.65 in (29 mm x 29 mm x 42 mm) |
| Operating Temp | -22 °F to 122 °F (-30 °C to 50 °C) |
| Storage Temp | -22 °F to 176 °F (-30 °C to 80 °C) |
| Power Consumption | 12 V to 3.2 W |
| Power Input | DC 6 V to 24 V, Supporting PoE |
| Interface | USB 3.0 |
| Conformity | USB 3 vision |
