Technical Specifications
| Optical Geometry | D per 8 (diffuse lighting, 8 ° viewing angle) |
| SCI Or SCE | (mirror component included) or (mirror component excluded) include UV or excluded UV light source |
| Characteristic | 0.3 in (8 mm) or 0.1 in (4 mm) apertures, free switch, good for horizontal or vertical measurement, wider adaptability. Accurate measurements can be used for accurate analysis and transfer of laboratory colors. Suitable for precise color measurement and quality control in textile and apparel printing and dyeing, plastic electronics, ceramics and other industries. It can be used for fluorescence sample measurement. |
| Ball Size Is Integrated | 1.5 in (40 mm) |
| Light Source | Combined full-spectrum LED light source, UV light source |
| Spectrophotometric Mode | Flat grid |
| Sensor | Silicon photodiode array (double row, 40 groups) |
| Wavelength Range | 400 nm to 700 nm |
| Wavelength Interval | 10 nm |
| Half Bandwidth | 10 nm |
| Observer Angle | 2 ° or 10 ° |
| Measured Reflection Area | 0% to 200% |
| Measuring Opening | MAV 0.3 in (8 mm) or 0.3 in (10 mm), SAV 0.15 in (4 mm) or 0.19 in (5 mm) |
| Mirror Component | SCI or SCE |
| Color Space | CIE LAB, XYZ, YXY, LCH, CIE LUV, s-RGB, HunterLab, βxy, DIN Lab99 Munsell (C per 2) |
| Color Difference Formula | E x ab, E x uv, E x 94, E x cmc, E x cmc, E x 00, DIN E99, E (Hunter) |
| Data Displayed | Spectrogram or values, sample chromaticity values, color difference values or diagram, pass or fail result, color simulation, color offset |
| Measuring Time | Approximately 1.5 seconds (measure SCI and SCE approximately 3.2 seconds) |
| Repeatability | Chromaticity value MAV or SCI, within E x from 0.02 (when a white calibration plate is measured 30 times at 5 second intervals after white calibration) |
| Cross-device Error | MAV or SCI, within E x from 0.15 (average for 12 BCRA II series color patches) |
| Measurement Mode | Single measurement, average measurement (2 times to 99 times) |
| Localization Method | Camera Is located |
| Battery | DC 24 V, 3 A power supply |
| Lifespan Of The Lamp | 5 years, more than 3 million measurements |
| Show | 7 in (17.7 cm) TFT color LCD, capacitive touch screen |
| Data Port | USB, Bluetooth 5.0, trigger switch interface |
| Data Storage | Standard 1000 pieces, example 30000 pieces |
| Language | Simplified Chinese, English, Traditional Chinese |
| Working Temperature | 32 °F to 104 °F (0 ℃ to 40 ℃) |
| Working Humidity | 0% to 85% (without condensation) |
| Storage Temperature | -4 °F to 122 °F (-20.0 ºC to 50.0 ºC) |
| Storage Humidity | 0% to 85% (without condensation) |
| Dimensions | 14.5 in x 9.4 in x 10.2 in (370 mm x 240 mm x 260 mm) |
| Weight | About 1.2 lb (7.8 kg) |
