Overview
Enviro Testers wireless metal paint color colorimeter is developed by combining advanced color sensors with rich APP applications. It adopts the 45/0 (45 ring-shaped illumination, vertical viewing) geometric optical structure in line with CIE No.15 and realizes the integration of the micro color difference meter and the mobile phone color reader. It is commonly used for color difference quality control in plastic electronics, paint coatings, textile and garment printing and dyeing, ceramics and other industries. You can identify and find color cards through mobile phone APP, and you can use it anytime and anywhere to capture color inspiration.
Technical Specifications
| Lighting Source | Full spectrum LED light source |
| Spectroscopic Methods | Light filter splitting |
| Sensors | CMOS dual optical path sensor |
| Measurement Wavelength Range | 400 nm to 700 nm |
| Wavelength Interval | 10 nm |
| Diameter | 0.31 in (8 mm) |
| Angle of Observer | 2° or 10° |
| Illumination | D65, A, C, D50, D55, D75, F1, F2(CWF), F3, F4, F5, F6, F7(DLF), F8, F9, F10(TPL5), F11(TL84), F12(TL83 or U30), U35, NBF, ID50, ID65 (Mobile APP implementation) |
| Measuring Time | About 1 second |
| Inter-instrument Error | ΔE x 00 < 0.4 (BCRA II series 12 color bricks measured average) |
| Display Precision | 0.01% |
| Battery | Lithium battery, can do tests continuously for 12000 times in a single full charge |
| Light Source | Lifespan 5-years more than 3 million times measurements |
| Display | 2.89 cm (1.14 in) IPS Color LCD |
| Interface | Type C USB |
| Bluetooth | 5.0 Buttons |
| Store the Data Standards | 10 pcs, Samples 100 pcs. Mass storage can be expanded through mobile APP |
| Altitude | lower than 1.243 mi (2000 m) |
| Operating Temperature | 32 °F to 104 °F (0 ℃ to 40 ℃) |
| Range Temperature Range | 68 °F to 122 °F (20 ℃ to 50 ℃) |
| Relative Humidity | 0% to 85% |
| Size | 1.18 in x 3.94 in (30 mm x 100 mm) |
| Weight | About 3.10 oz (88 g) |
