| Specification |
Details |
| Measurement Principle |
Magnetic induction (ferrous substrates) |
| Measurement Range (Scale 1) |
0 to 1,500 µm (0 to 60 mil) (0.1 µm res. up to 100 µm; 1 µm thereafter) |
| Measurement Range (Scale 2) |
0 to 5 mm (0 to 200 mil) (1 µm res. up to 1 mm; 10 µm thereafter) |
| Measurement Range (Scale 3) |
0 to 13 mm (0 to 500 mil) (1 µm res. up to 2 mm; 10 µm thereafter) |
| Accuracy (Scale 1) |
±1–3% or ±2.5 µm (±0.1 mil), whichever is greater |
| Accuracy (Scale 2) |
±1–3% or ±20 µm (±1 mil) ( |
| Accuracy (Scale 3) |
±1–3% or ±50 µm (±2.0 mil) |
| Display Type |
2.4-in colour TFT LCD (320 × 240 pixels), auto-rotate, backlit |
| Reading Rate |
Over 70 readings per minute |
| Memory and Data Storage |
150,000 readings in 2,500 batches, data output via USB & Bluetooth® |
| Durability and Design Features |
IP64-rated, rugged and impact-resistant casing, large ‘Bigfoot™’ integral probe for one-handed use |
| Calibration Options |
1-Point, 2-Point, Zero-offset, + ISO / SSPC predefined modes, automatic option, calibration lock with PIN |
| Power Supply and Battery Life |
2 × AA batteries (rechargeable OK), ~24 hr continuous runtime at 1 reading per second |
| Operating Temperature |
14 °F to 122 °F (–10 °C to +50 °C) |
| Product Weight (Incl. Batteries) |
5.50 oz (156 g) |
| Dimensions (H × W × D) |
5.55 in × 2.87 in × 1.46 in (14.1 × 7.30 × 3.70 cm) |
