Features
- High-Resolution Thermal Imaging – 240×240 thermal pixel resolution with IR resolution of 96×96.
- 6 Colour Palettes – Multiple viewing modes (rainbow, iron, white hot, black hot, etc.) for flexible analysis.
- Wide Field of View – 50° × 50° angle, covering larger areas in one scan.
- Fast Image Frequency – 25Hz frame rate ensures smooth and accurate image capture.
- High Thermal Sensitivity – NETD ≤60mK at 25°C, detecting even minor temperature differences.
- Industrial Temperature Range – Measures -20℃ to 550℃ with ±2℃ or ±2% accuracy.
- Long Battery Life – Built-in 3200mAh rechargeable battery supports ≥7 hours of continuous use.
- Multiple Temp Measurement Modes – Centre point, max, and min temperature display.
- Durable & Portable – IP54 rating, 1.5m drop resistance, lightweight (0.7kg) design.
- Flexible Data Storage & Transfer – External SD card storage with Type-C interface, supports JPEG/MP4 formats.
- PC Analysis Tool – Supports thermal data export and analysis on PC.
- Multi-language Support – Operates in 10 different languages for global usability.
Technical Specifications
| Parameter | Specification |
| Model Number | YXI96 |
| Detector Type | VOx |
| Thermal Image Pixel | 240×240 |
| IR Resolution | 96×96 |
| Thermal Sensitivity (NETD) | ≤60 mK (@25°C, F#1.0) |
| Field of View (FOV) | 50° × 50° |
| IFOV | 8.89 mrad |
| Pixel Spacing | 12 μm |
| Image Frequency | 25Hz |
| Focal Length | 1.35mm |
| Focal Adjustment | Fixed focus |
| IR Wavelength | 8–14 μm |
| Temperature Range | -20℃ ~ 550℃ (-4℉ ~ 1022℉) |
| Accuracy | ±2℃ or ±2% of reading |
| Temperature Unit | ℃ / ℉ / K |
| Minimum Scale | 0.1℃ |
| Measurement Modes | Industrial temperature measurement |
| Temp Display Modes | Centre point / Max temp / Min temp |
| Colour Palettes | 6 colour palettes |
| Image/Video Mode | IR imaging, JPEG / MP4 recording |
| Photo/Video | Supported |
| Storage Memory | External SD card |
| Data Port | Type-C |
| TISR | Supported |
| Image Frame Rate | 25Hz |
| PC Analysis Tool | Supported |
| Battery | 3200mAh (non-removable) |
| Battery Life | ≥7 hours |
| Charging Time | ≤4 hours |
| Power Consumption | ≤1.4W |
| Drop Resistance | 1.5m |
| IP Rating | IP54 |
| Working Temperature | -10℃ ~ 50℃ |
| Storage Temperature | -40℃ ~ 60℃ |
| Operating Humidity | 10%–90% RH, non-condensing |
| Language Support | 10 languages |
| Certifications | CE, FCC, RoHS |
| Net Weight | 0.7 kg |
| Package Size | 18 × 25 × 15 cm |
