Features
- High Resolution Imaging: 256×192 thermal pixels with 640×512 visible light resolution.
- Clear Display: 2.8-inch colour LCD screen (320×240 resolution).
- Wide Measuring Range: -20℃ to 550℃ (-4°F to 1022°F) with ±2% or ±2℃
- WiFi Transmission: Real-time image transfer for fast analysis.
- Multiple Colour Palettes: Rainbow, Iron Red, Cool, White Hot, and Black Hot.
- Recording & Storage: Supports JPG/MP4 format and SD card storage up to 3GB.
- Durable & Portable: Lightweight 375g design with ergonomic handheld style.
- Long Battery Life: Built-in 2000mAh rechargeable lithium battery with 2–3 hours runtime.
- User-Friendly Functions: Adjustable emissivity (0.1–1.0), date/time format, automatic shutdown, and multi-language support.
- Versatile Applications: Building inspections, water leak detection, HVAC maintenance, automotive diagnostics, and industrial equipment monitoring.
Technical Specifications
| Item | Details |
| Display Screen | 2.8″ Colour LCD (320×240) |
| Thermal Resolution | 256×192 |
| Visible Light Resolution | 640×512 |
| Measuring Range | -20℃ ~ 550℃ (-4°F ~ 1022°F) |
| Accuracy | ±2% / ±2℃ |
| Frame Rate | 25Hz |
| Emissivity | 0.1–1.0 adjustable |
| Thermal Sensitivity (NETD) | ＜50mK @ F#1.0 |
| IFOV (Spatial Resolution) | 3.75mrad |
| Pixel Spacing | 12μm |
| Spectral Range | 8–14μm |
| Field of View / Lens | 56° × 42° / 3.2mm |
| Focus Mode | Fixed |
| Colour Palettes | Rainbow, Iron Red, Cool, White Hot, Black Hot |
| Storage | JPG/MP4 on SD card (3GB) |
| Battery Type | Built-in 3.7V 2000mAh rechargeable lithium battery |
| Battery Life | 2–3 hours |
| Charging Interface | Micro USB 2.0 |
| Size | 96 × 72 × 226 mm |
| Weight | 375g |
| Operating Temperature | -20℃ ~ 550℃ |
| Relative Humidity | 10% RH ~ 80% RH |
| Software Functions | Analysis, recording, localization, language, auto-shutdown |
