Hydrogen Bromide (HBr) Gas Detector with High Precision and IP68 Protection – Enviro Testers

Overview

Enviro Testers hydrogen bromide (hbr) gas detector with high precision and ip68 protection is a cost-effective and intrinsically safe gas detector for the continuous monitoring of toxic gases, oxygen, flammable gases. With IECEx, ATEX certificates, explosion level reaches Ex db IIC T6 GB/Ex db ia IIC T6 GB/Ex da db ia IIC T6 GB. Having a 3-wire 4 to 20 mA analog output with relays, it also offers HART, RS485 Modbus protocol, making it compatible with most control systems. With optional wireless function, no need wires to save the labor cost and realize the transmission without limits. Adopt magnetic wand design, it’s safe and easy to do menu navigation in explosion areas. It is also an intelligent hot swappable fixed gas detector, which is easy for maintenance after installation.



Features

• IP66/IP68 water & dust resistant

• Module chamber design, no need to disassemble of the whole machine or return for calibration when maintenance, just replace the sensor chamber only and can work properly

• One-person calibration is easily performed using calibration cap

• Body weight is only 1 kg, easy to install by one-person

• Quick site installation using a mounting plate accessory

• Standard 4-20 mA current signal, RS485 Modbus, 1 set of relay signal output

• Optional with 2 sets of relay signals, voltage 1 V to 5V

• Optional HART digital communication provides configuration

• Optional wireless transmission modes can be selected



Technical Specification

Gas Detected	HBr (Hydrogen Bromide)
Detection Principle	Electrochemistry
Measurement Range	0 ppm to 10 ppm
Resolution	0.1 ppm
Accuracy	≤±2-5%FS (Depending on the specific sensor)
Explosion-Proof Grade	IECEX: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb ；ATEX: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb
Protection Grade	IP66/68
Power Dissipation	Toxic gas <2.5W, Flammable gas <4W
Communication Mode	4 mA to 20mA (3-wires), RS485, 1 V to 5V, Hart (Optional)
Wireless Options	LORA, GPRS/4G (Optional)
Working Voltage	12VDC to 24VDC
Contact Capacity	Standard: 1 set of relay signals, Optional: 2 sets
Display	LED display
Working Temperature	-40°F to 158°F (-40℃ to 70℃) (Catalytic sensor), -4°F to 122°F (-20℃ to 50℃) (Electrochemistry sensor)
Working Pressure	86 kPa to 106 kPa
Housing Material	Die-cast aluminum
Electrical Interface	Standard: Internal screw thread M20 * 1.5, Optional: 1/2NPT internal thread, G3/4, G1/2, 3/4NPT
Size	6.21 in × 5.07 in × 2.74 in (15.78 cm × 12.88 cm × 6.96 cm)
Weight	About 2.20 lb (1 kg)
