Overview
Enviro Testers’s Industrial Gas Detector with OLED Display and Alarm is a smart device that supports the customization of more than 300 kinds of gases, such as CO, EX, H₂S, CO₂, O₂, CH₄, SO₂, HCL, etc., and supports customization of different ranges. This gas detector has various communication methods and displays data in real time. This product uses a 2.4-inch industrial-grade OLED screen with high stability, high accuracy, and high intelligence.
Features
- Versatile Gas Detection: Customizable for over 300 types of gases, including common industrial gases like CO, O₂, H₂S, and CH₄.
- Clear Display: Features a large 2.4-inch high-definition OLED screen for clear, real-time data readings.
- Integrated Alarms: Equipped with both sound and light alarm indicators for immediate alerts.
- Advanced Sampling: Uses the diffusion sampling method for reliable gas detection.
- User-Friendly Operation: Supports remote control and features a switchable Chinese and English interface.
- Data Storage: Includes an SD memory card slot and FLASH memory for data logging.
Application
It’s ideal for use in chemical plants, manufacturing facilities, storage areas, and other locations where gas leaks pose a potential hazard.
Technical specifications
| Product Type | Fixed Gas Detector |
| Sensor Type | Electrochemical or Catalytic Combustion or Semiconductor |
| Sampling Method | Diffusion |
| Detecting Range | 3.0% LEL to 100.0% LEL |
| Resolution | 0.1% LEL |
| Indication Error | ±3% LEL |
| Response Time | Less than 30s |
| Zero Drift | ≤±2% FS or years |
| Operating Voltage | 24 V ±15% |
| Housing Material | Die-cast Aluminum |
| Connection Port | M27 x 1.5 mm |
| Relay Output | Three groups, contact capacity: 30 VCD 2C |
| Working Pressure | 86 kPa to 106 kPa |
| Explosion-proof Sign | Exib IIC T6 GB |
| Protection Grade | IP66 |
| Working Humidity | ≤90% RH |
| Operating Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Weight | 4.63 lbs (2.1 kg) |
| Dimensions | 10.24 in x 7.54 in x 4.47 in (260 mm x 191.5 mm x 113.5 mm) |
