Features
- Conductivity cell 4-electrode, automatic range switching, easy to clean
- Protection grade IP68, can work continuously under water for a long time
- Standard Modbus protocol, support access to standard industrial control system
- No polarization, can be used continuously online
- Extremely wide range, wider application
- Very resistant to pollution, strong anti-interference ability
- Stable measurement and higher accuracy
- Strong and durable structure, longer service life
Technical Specifications
| Signal Type | Modbus |
| Accuracy | ± 1% of full scale |
| Resolution | 0.1 μS or cm |
| Temperature Compensation | Automatic, Built-in temperature unit |
| Communication | Modbus RTU, RS485 interface |
| Calibration Method | One-point or 2-point calibration |
| Customized Support | OEM |
| Type | Water Sensors |
| Protection Grade | IP68 |
| Working Pressure | 0 Bar to 6 Bar |
| Power Supply | 6 V to 12 V DC |
| Shaft Material | Ti + PEEK + Nickel |
| Size | No |
| Battery | No |
| Dimensions | Diameter 0.866 in (22mm) length 5.78 in (147 mm) |
| Installation | Submersible; Thread specifications: M 0.86 in x 0.05 in (22 mm x 1.5mm) |
| Measuring Range | 0.0 mS/cm to 100.0 mS/cm |
| Operating Temperature | 32 °F to 122 °F (0 ℃ to 50 ℃) |
