Technical Specifications
| Illumination Or Observation System | D or 8 (diffused illumination, 8-degree viewing angle) Conforms to CIE No.15, GB or T 3978. |
| Integrating Sphere Size | Φ 2.28 in (58 mm) |
| Light | Combined LED sources |
| Senso | Silicon photodiode array |
| Wavelength Range | 400 nm to 700 nm |
| Wavelength Pitch | 10 nm |
| Reflectance Range | 0% to 200% |
| Measuring Aperture | Φ 0.31 in (8 mm) |
| Color Space | CIE LAB, XYZ, YXY, LCH, CIE LUV, LAB and WI and YI |
| Color Difference Formula | Δ E x ab, Δ E x u v, Δ E x 94, Δ E x CMC (2 1), Δ E x CMC (1 1), Δ E x cm c (l c), CIE 2000 Δ E x 00, Δ E (h) |
| Other Chromaticity Data | WI (ASTM E 313, CIE or ISO, AATCC, Hunter), YI (ASTM D 1925, ASTM 313), Metamerism index (Mt), Color strength color stain, Color fastness |
| Observer | 2° or 10° |
| Illuminant | D 65, D 50, A, C, D 55, D 75, F 1, F 2, F 3, F 4, F 5, F 6, F 7, F 8, F 9, F 10 |
| Display Data | Spectral value or Graph, Colorimetric value, Color difference value or Graph, Pass or Fail result, Color offset, Color simulation, Color index setting (Δ E x 94, Δ E x CMC, Δ E 2000), Tolerance prompt, Reverse prompt, Time setting, language setting, Restore factory setting |
| Measurement Time | 1.5 s |
| Repeatability | Spectral reflectance Standard deviation within 0.1% (400 nm to 700 nm within 0.2%) Colorimetric value Standard deviation within Δ E x ab 0.04 (Measurement condition White calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.) |
| Inter Instrument Agreement | Within Δ E x ab 0.2 (Average for 12 BCRA Series II color tiles) |
| Battery | Li-ion battery. 2800 times within 8 hours. |
| Lamp Life | 5 years, more than 1.6 million measurements |
| Display | 3.5 (8.89 cm) TFT LCD, Capacitive touch screen |
| Interface | USB or RS-232 |
| Data Memory | 1000 Standards, 15000 Samples |
| Ambient Temp. | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temp. | -4 °F to 122 °F (-20 °C to 50 °C) |
| External Size | 3.54 in x 3.03 in x 9.06 in (90 mm x 77 mm x 230 mm) |
| Net Weight | 21.16 oz (600 g) |
| Gross Weight | 20.94 lb (9.5 kg) |
