Overview
Enviro Testers Thickness Tester with Sound Velocity measures metal, plastic, glass etc., offers coupling alert, choose diff frequency, long measuring range & Accuracy
Key Features
l Suitable for measuring metal (such as steel, cast iron, aluminum, copper, etc.), plastic, ceramic, glass, glass fiber and other any good conductors of ultrasonic thickness.
l Can be equipped with a variety of different frequency, chip size, double crystal probe use.
l Have probe zero calibration, a two-point calibration function, can be automatically on system error correction.
l Thickness can be known the sound velocity measurement, in order to improve the accuracy of measurement.
l With functions of coupling status alerts.
l LED backlight display, convenient to use in dark environment.
l The battery indicator function, can real-time display the battery remaining power.
l With automatic power saving function dormancy, automatic shutdown, etc.
l Small, portable, high reliability, suitable for bad operating environment, vibration, impact resistance and electromagnetic interference.
l The background data processing function; PC communication function; printing support.
Technical Specifications
| Measuring range: | 0.75mm~300.0mm(0.03inch~11.8inch) |
| Units: | Metric/Imperial unit selectable |
| Sound Velocity Range: | 1000m/s~9999m/s(0.039~0.394in/μs |
| Display resolution: | (0.01mm or 0.1mm)
(0.1mm)(more than 99.99mm) |
| Accuracy: | ±(0.5%Thickness+0.04), depends on Materials and conditions |
| Data Memory: | 6 files(up to 100 values for each file)of stored values
5 Sound Velocity of stored values |
| Power Source: | 2pcs 1.5V AA size,batteries.250 hours typical operating time(LED backlight off) |
| Outline Dimensions: | 5.9*2.9*1.2 in (150mm*74mm*32mm) |
| Workpiece surface temperature: | 14 ~ 140F(- 10 ~ 60 ℃ ) |
| Weight: | 0.52lbs.(238 g) |
| Power source: | Type AA alkaline battery 1.5 V (2) |
| Optional attachments: | 2 MHZ, 7 MHZ and 5 MHZ (high temperature) |
