| Measuring Range |
0 µm to 1250 µm with standard probe |
| Probes Available |
5 probes for F (ferrous: on steel or iron) and N (non-ferrous metals) |
| Tolerance |
F1: ±(1μ+3%H), N1 ± (1.5μ+3% H) |
| Resolution |
Alphanumeric with 4 large digits |
| Standards |
DIN, ISO, ASTM, BS |
| Min. Measuring Area |
F1:(standard probe) |
| Min. Curvature Radius |
Convex:3, Concave:50 |
| Min. Substrate Thickness |
Type F: 0.5 |
| Calibration |
One point, Two-point, Basic calibration |
| Statistics |
Maximum and minimum of 3000 readings |
| Data Memory |
500 measuring data |
| Limits |
Adjustable with acoustic alarm |
| Interface |
USB 2.0 |
| Operating Temperature |
32 °F to 104 °F (0 ℃ to 40 ℃) |
| Power Supply |
AA size 1.5 V |
| Dimensions |
4.92 in x 2.64 in x 1.23 in (125 mm x 67 mm x 31 mm) |
| Weight |
0.764 lb (345 g) |
