Features
- Perfect combination of beautiful appearance
- Can be used in color matching and accurate color transmission
- 3.5 in (8.89 cm) TFT color LCD touch screen, concave grating
- Use long life and low power consumption combined LED light source
- Single 0.31 in (8 mm) aperture, support both SCI and SCE at the same time
- Large capacity storage space, over 20,000 measurement data
- Camera Locating Function, better position
- PC software has a powerful function extension
Technical Specifications
| Optical geometry | Reflect di 8°, de 8° (diffused illumination, 8-degree viewing angle) |
| Light source | Combined LED light |
| Spectrophotometric mode | Concave grating |
| Sensor | 256 image elements double array comes image sensor |
| Wavelength range | 400 nm to 700 nm |
| Wavelength interval | 10 nm |
| Semi bandwidth | 10 nm |
| Power supply | Li-ion battery |
| Calibration | White and Black Calibration Cavity |
| Measured reflectance range | 0% to 200% |
| Measuring aperture | Single aperture 0.31 in (8 mm) or 0.39 in (10 mm) |
| Specular component | SCI and SCE |
| Integrating sphere size | 1.89 in (48 mm) |
