Features
- Bluetooth connects for data sharing.
- Print gas results via compatible printers.
- Detect low gas levels with high sensitivity.
- Real-time monitoring for instant readings.
- Visual & audible alarms signal hazards.
- Long historical gas concentrations.
- Robust build for industrial settings.
- User-friendly interface for easy use.
- Long battery life extends usage.
- Calibrate for accuracy as needed.
- Integrate with broader systems.
- Suitable for hazardous locations.
Technical Specifications
| Response time | ≤20 s (T90) |
| Work principle | Electrochemical sensor |
| Gas type | NOx |
| Measure range | NO2: 0 to 20ppm |
| Repeatability | ≤±1% |
| Precision | ±3% F.S |
| Resolution | 0.01 ppm |
| Data storage function | With the capacity of the 100000 group of measuring data, by thesoftware could be transmitted to the computer. |
| Display | LCD displays the Date, time, Temp& humidity, Gas concentration data, unit, status for the pump, alarm and battery. |
| Operation language | Chinese/English |
| Working pressure | -30 PSI to 100 PSI |
| Recovery time | ≤20 s |
| Linearity | ≤±1% |
| Concentration unit | ppm, %vol, % lel, mg/m3 |
| Alarm mode | Audible, visual, vibration |
| Working humidity | 0% to 95% RH (non-condensing) |
| Dimensions | 8.66 in x 3.46 in x 2.16 in (220 mm x 88 mm x 55mm) |
| Weight | 1.102 lb (500 g) |
| Working temperature | -40 ℉ to 248 ℉ (-40 ℃ to 120 ℃) |
