Features
- Modular NDIR and ECD sensors design, easy for maintenance
- Compact design, easy carrying among different sites
- Auto temperature compensation to guarantee precision
- Precision filters to remove moisture and dust in sample gas for analyzer protection
- Rechargeable Lithium battery supports up to 8 hours continuous working
- In-built memory for up to 2560 units of records, easy to download the data to PC
Technical Specifications
| Standard Measurement | CH4, CO2, H2S, O2 |
| Optional measurement | CO, H2 (optional) |
| Technology | CH4, CO2(NDIR) H2S, O2, CO, H2(ECD) |
| Range | CH4: 0% to 100%
CO2: 0% to 50% H2S: 0 ppm to 9999 ppm O2: 0 to 25% CO: 0 ppm to 2000 ppm H2:0 ppm to 2000 ppm |
| Resolution | CH4, CO2, O2: 0.01%, H2S, CO, H2: 1ppm |
| Precision | CO2, CH4: <2%FS H2S, O2, CO, H2: <3%FS |
| Inlet gas flow | 0.7 L/min to 1.2 L/min |
| Inlet gas pressure | 2 PSI to 50 PSI |
| Sampling gas condition | No dust, No water, No tar |
| Response time(T90) | <10s (NDIR) |
| Display | High-resolution colored 3.2-inch |
| Communication interface | USB port, Bluetooth 4.0 |
| Lithium battery pack | Rechargeable |
| Work temperature | 14 °F to 104 °F (-10 °C to 40 °C) |
| Relative humidity | <95% non-condensing |
| Ambient pressure | 70 PSI to 120 PSI |
| Dimension | 11.6 in x 7.72 in x 2.44 in (295 mm x 196 mm x 62 mm) (LWH) |
| Weight | 2.65 lb. (1.2kg) |
