Technical Specifications
| Detection Temperature Of Normal Temperature Probe | -13 °F to 392 °F (-25 ℃ to 200 ℃) |
| High Temperature Probe Detection Temperature | 392 °F to 1112 °F (200 ℃ to 600 ℃) |
| Detection Range | 0.04 in to 7.87 in (1 mm to 200 mm) (expandable to 15.75 in (400 mm)) |
| Gain | 0 dB to 80 dB (adjustment accuracy: 0.1 dB or 2 dB or 6dB) |
| Equivalent Input Noise | < 80 × 10 or 9 V /Hz1/2 |
| Attenuator Accuracy | < ± 1 dB or 12 dB |
| Vertical Linear Error | < 3 % |
| Horizontal Linear Error | < 0.2 % |
| Battery | 7.4 V DC, lithium battery, continuous working for 4 hours |
| Size | 0.87 in x 4.92 in x 1.57 in (22 mm x 125 mm x 40mm) |
| Machine Weight | 1.65 lb (0.75 kg) |
