Overview
The Enviro Testers advanced multi-channel water quality analyzer is designed for precise detection of oil in water and pH levels.It supports multiple digital sensors with high accuracy, real-time monitoring, and customizable outputs.Built with industrial-grade PC+ABS housing, it ensures durability and IP55 protection.Ideal for wastewater treatment, thermal power plants, and laboratory monitoring application.
Features
- Multi-Channel Sensor Support – Connect up to 4 digital sensors for versatile monitoring.
- High-Resolution Touchscreen – 4.3″ (109 mm) / 5″ (127 mm) full-color display with intuitive interface.
- Accurate Measurement – Fluorescence method for oil in water detection and full pH range (0.00–14.00).
- Dual Output Options – Multiple 0/4–20 mA analog outputs with maximum load of 500 Ω.
- Reliable Relays – 3-way or 6-way SPDT relay for external device control.
- Durable Build – IP55 protection with robust PC+ABS housing for harsh environments.
- Automatic Cleaning – Mechanical brush system reduces manual maintenance.
- Wide Operating Range – Functions efficiently between -10–60 °C (14–140 °F).
- Flexible Communication – RS485 (Modbus RTU) and RS232 outputs, supporting baud rates up to 115200 bps.
- Industrial Applications – Ideal for wastewater monitoring, thermal power plants, and laboratory use.
Technical Specifications
| Specification | Details |
| Frequency / Communication Mode | RS485 (Modbus RTU), Max Baud Rate 115200 bps |
| Support Type | All digital sensors |
| Analyser Interface | Supports connection of 1, 2, or 4 digital sensors |
| Analog Output | 2 or 6 channels, 0/4–20mA (max load 500Ω) |
| Relay | 3-way or 6-way SPDT relay (120VAC, 24VDC/1A) |
| Digital Output | 1 × RS485, 1 × RS232 |
| Measurement Parameters | Oil in water (Crude Oil), Temperature, pH |
| Measurement Method | Fluorescence method, Immersion measurement |
| Measuring Range | – Oil in water: 0–500 mg/L – Temperature: 0–60°C (32–140°F) – pH: 0.00–14.00 pH |
| Cleaning Method | Mechanical brush automatic cleaning |
| Display | 4.3-inch or 5-inch Color Touchscreen Resolution: 480×272 or 800×480 |
| Power Supply | 220 V AC |
| Power Consumption | ＜4W or ＜6W (depending on configuration) |
| Protection Level | IP55 |
| Shell Material | PC, ABS |
| Customized Support | OEM, ODM, OBM |
| Application | Wastewater, Thermal power plant, Laboratory |
| Connection | Upper & Lower 3/4 NPT Pipe Thread |
| Storage Temperature | -20–70°C (-4–158°F) |
| Working Temperature | -10–60°C (14–140°F) |
